Intermec PC43t User Manual

Chapter 2 — Set Up the Printer
38 PC23 and PC43 Desktop Printer User Manual
Load Media for Tear-Off Printing
Depending on the type of media you use, you may also need to install
a printer accessory. If you need to print on tag media, Intermec
recommends installing the optional thick media springs before
printing. If you need to print on linerless media, you must install the
linerless media roller accessory before printing.
1 Pull one or both of the printer latches toward the front of the
printer and lift the printer lid.
2 If there is an empty media core in the media compartment, remove
the core.
Note: When removing printed labels on linerless media, tear the label
up towards the top of the printer to prevent media jams.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
