Intermec PC43t User Manual

Appendix B — Default Settings
150 PC23 and PC43 Desktop Printer User Manual
Print Quality Settings
This section describes print quality settings. To view these settings:
• From the printer Main Menu, select Settings > Printing > Print
Quality.
• From the printer web page, click the Configure tab, Printing >
Print Quality.
Length (Slow
Mode)
If Media Calibration Mode is set to Slow,
the printer prints the media length plus 10
mm. This value sets an additional amount
of media to be printed. Unit of
measurement is defined in the Unit of
Measurement parameter. Range is 0 to
3200.
0
LTS
Sensitivity
Level
Sets the sensitivity of the label taken sensor.
Range is 0 to 14. Supported when the
Cutter or Label Dispenser accessories are
installed.
0
Media Settings (Continued)
Setting Description Default
Print Quality Settings
Setting Description Default
Print Speed Sets how fast the printer prints labels. The
unit of measure is defined in the Unit of
Measure parameter.
100
Media Sensitivity Sets the level of sensitivity of the media to the
printhead heat for media and ribbon.
Variable
Darkness Sets the image darkness for media and ribbon.
Adjust this parameter with the Media
Sensitivity parameter. Range is 1 to 100.
Variable
Contrast Adjusts the blackness of the printing on the
label in 2% increments from -10% to +10%.
+0%

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
