Intermec PC43t User Manual

Chapter 2 — Set Up the Printer
62 PC23 and PC43 Desktop Printer User Manual
3 Press to select Tools and then press . The Tools menu appears
with Test Labels selected.
4 Press .
5 Select Print Quality, Printer Information, or Printer Settings,
and then press
. A list of available labels appears.
6 Select a label to print, and then press .
How to Print on RFID Media
If you have an LCD printer with the optional RFID module installed,
you can print on RFID media. Media containing RFID tags is slightly
thicker where the RFID tag is located. The slight thickness of this part
of the label may affect print quality. For thermal transfer labels,
Intermec recommends using high-quality ink ribbon.
To achieve the best possible print quality, follow these guidelines:
• Run the RFID calibration wizard to determine the best Tag
Position and Output Power for RFID media.
• If necessary, modify the Tag Position (TAGADJUST variable) to
make sure the RFID labels are properly aligned with the antenna.
• Avoid printing on the thickest part of the label when possible.
For help configuring RFID parameters, see the Intermec Fingerprint
Command Reference Manual or the IPL Command Reference
Manual.
Test Labels
Print Quality
Resources
Printer Information
Printer Settings

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
