Intermec PC43t User Manual

Chapter 5 — Troubleshoot the Printer
114 PC23 and PC43 Desktop Printer User Manual
Upgrade Firmware from the USB Menu
If you have an LCD printer, you can upgrade the printer firmware
through the USB menu. This procedure is different from upgrading
firmware from a USB storage device without going through the USB
menu.
1 Make sure the USB storage device has a single partition and is
formatted as FAT16 or FAT32.
2 Download the printer firmware from the Intermec website.
3 On your USB storage device, create a /firmware directory.
4 Copy the firmware upgrade file (typically .bin format) to the
/firmware directory on the USB storage device.
5 Insert the USB storage device into the printer USB host port. The
USB Menu appears.
6 In the USB Menu list, select Upgrade Firmware.
7 In the Upgrade Firmware list, select the firmware upgrade file and
press
. An “Upgrade Firmware?” message appears.
8 Press to start the upgrade. When the upgrade is complete, the
printer restarts and the Ready screen appears.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
