Intermec PC43t User Manual

Chapter 4 — Configure the Printer
PC23 and PC43 Desktop Printer User Manual 93
Export or Upload Applications and Files
This topic explains how to upload applications and files to the printer
using a USB storage device.
You can also export applications and files from the printer to the
storage device.
1 Make sure the USB storage device has a single partition and is
formatted as FAT16 or FAT32.
2 Copy the files to the appropriate directory on the USB storage
device.
3 Insert the storage device into the USB host port on the printer. The
USB Device menu appears.
4 Select an item in the USB Device list:
• To upload an application or other file into the printer memory
from the USB storage device, select Install Resources and then
press
.
• To export an application or file from the printer to the USB
storage device, select Export Resources and then press
.
5 Select the type of item you want to upload or export (Applications,
Fonts, Forms/layout, Web Forms, Images, or FP Scripts) and
then press
.
6 Select the file from the list and then press . The file is uploaded
to the printer memory or exported to the USB storage device.
Upload or Delete Applications and Resources
From the printer web page, use the Manage page to upload or delete
applications, fonts, images, label formats, or web forms.
Note: You can only export applications and files that you previously
uploaded to the printer memory.
Note: You can only delete applications and resources you downloaded
to the printer memory. You cannot delete resident applications or
resources, which are installed as part of the printer firmware.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
