Intermec PC43t User Manual

Chapter 3 — Connect the Printer
70 PC23 and PC43 Desktop Printer User Manual
Connect the Printer Using a USB Cable
The printer supports USB connections to a desktop PC. You do not
need to set up any parameters for USB communications.
1 Download and install the InterDriver software on your PC.
2 Connect one end of the USB cable to the back of the printer and
connect the other end to your PC.A “USB Host Connected”
message appears on the printer screen.
Connect the Printer Using a Serial or Parallel Cable
If you have the optional USB-to-Serial adapter cable or USB-to-Parallel
adapter cable for the printer, you can connect the printer to the serial
or parallel port on a PC.
Note: You must install InterDriver to use a USB connection to a
Windows PC. For more information, see the PrinterCompanion CD
that came with your printer.
64#EFWJDFQPSU
Note: You must configure all printer settings through the printer
Main Menu, the printer web page, or with PrintSet 5 and a USB
connection before you use a parallel connection to the printer.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
