Chapter 5 — Troubleshoot the Printer
PC23 and PC43 Desktop Printer User Manual 99
4 Click Statistics.
5 Click a category to see more information. For example, click Print
Statistics to see the number of labels printed and odometer values.
Check the Printer Odometer
You can check the odometer from the printer web page to see the
printhead usage and how the current values compare to the alert
values. To check the printer odometer from the printer web page, the
printer must be turned on and connected to your Wi-Fi or Ethernet
network.
1 On your desktop PC, start a browser.
2 In the Location or Address bar, type the printer IP address and
press Enter. The web page for the printer appears.
Statistic Description
System information Printer uptime and CPU usage, firmware and
kernel versions, printer configuration and serial
numbers, flash and RAM memory information.
Print Statistics Total labels printed, RFID tag success rate,
odometer values, total distance printed (printer
and current printhead).
Supply Printhead, media, and ribbon information.
Hardware Options Input/output devices, serial port information.
Administration Failed login tries, user information.
Network Interfaces MAC address, TCP/IP and 802.11 network
information.
Font Information Name, type, and size of installed fonts.
Bar Code Information Name and type of installed bar code fonts.
Image Information Name, type, and size of installed images.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
