Appendix A — Specifications
124 PC23 and PC43 Desktop Printer User Manual
Printer Specifications
PC23d Physical Specifications
Dimensions: 17.7 cm x 12.5 cm x 21.5 cm
(6.97 in x 4.92 in x 8.46 in)
Weight: 1.45 kg (3.20 lbs)
Power Supply Requirements: 100–240 VAC, 50–60 Hz, 60W
Operating Temperature: 5 °C to 40 °C (41 °F to 104 °F)
Storage Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Relative Humidity: 20 to 80% non-condensing
PC23d Print Speed, Resolution, and General Media Specifications
Print Mode: Direct thermal
Print Speed (variable): 203 dpi: 50 to 200 mm/sec (2 to 8 ips) 300
dpi: 50 to 150 mm/sec (2 to 6 ips)
Print Resolution: 203 dpi: 8 dots/mm300 dpi: 11.8
dots/mm
Print Width: 203 dpi: 54 mm (2.1 in) max 300 dpi: 56
mm (2.2 in) max
Media Width: 15 to 60 mm (0.59 to 2.36 in)
Label Roll Diameter (maximum): 127 mm (5 in)
Label Length (minimum): 6.35 mm (.25 in)
Gap Length Between Labels: 2 to 10 mm (0.08 to 0.39 in)
Black Mark Length 3 to 10 mm (0.12 to 0.39 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 76.2 to 203 μm (3 to 8 mil), flexible
wristbands up to 10 mils (maximum)
Media Density:
60 to 181 g/m
2
Liner Opacity (maximum): 76% (TAPPI T425)
Label Stop Sensor Adjustable from left media edge to 4.5
mm right of center on LCD printers
(fixed at center on Icon printers)

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
