Chapter 3 — Connect the Printer
PC23 and PC43 Desktop Printer User Manual 77
• the Bluetooth icon turns on in the icon printer interface.
The icon is white when the Bluetooth connection is active, and gray
when the connection is inactive or disabled.
Connect to a Bluetooth Device by Reading a Bar Code
To connect a Bluetooth-enabled bar code scanner to the printer, use
the scanner to read the “Scan to Connect” bar code.
1 Make sure your printer is ready to print.
2 On your desktop PC, start a web browser.
3 In the address field, type the printer IP address and then press
Enter. The printer web page appears.
4 Click Services and then select Print Test Labels > Printer
Settings.
5 In the Printer Settings screen, locate the Bluetooth Settings label
and click Print. The printer prints the Bluetooth Settings label.
Fingerprint
10.200.27.89
01/04/2012
12:00
®
Ready
#MVFUPPUIJDPO
#MVFUPPUIJDPO

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
