Intermec PC43t User Manual

Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 11
View Basic Printer and Connection Information
In the Ready screen, use the control panel buttons to select an icon in
the status bar at the top of the screen to view printer or connection
information.
1 Press any arrow key to select the one of the icons in the status bar
at the top of the Ready screen.
2 Press . A list of basic printer or connection information appears.
3 Press or to scroll through the list.
(Optional) Press or to view information for one of the other
icons.
4 Press or to return to the Ready screen.
Fingerprint
10.200.27.89
01/04/2012
12:00
®
1SJOUFSJOGPSNBUJPO
JDPOTFMFDUFE
4UBUVTCBS
Ready
A0000000000000002
S0000000411
PC43t
Firmware Version:
Product Name:
Printer Serial Number:
Printer Configuration Number
Printing

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
