Intermec PC43t User Manual

Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 59
8 Close the printer lid until it snaps shut.
9 If you have already configured the printer for thermal transfer
printing, continue with the next step. Otherwise, from the printer
Main Menu, select Settings > Printing > Media > Print Method >
Ribbon (TTR).
For an icon printer, you must use the printer web page or Intermec
PrintSet 5 to configure thermal transfer printing.
10 Save your changes.
Connect the Printer to Power
1 Connect the power adapter to the power port on the rear of the
printer.
2 Connect the power adapter to AC power. When the adapter is
connected to AC power, the green LED in the adapter connector
turns on and stays on.
Caution: Use only the AC power adapter supplied with the printer.
The use of a power adapter not approved by Intermec voids the
product warranty and may damage the printer.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
