Intermec PC43t User Manual

Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 21
Set the Command Language from the Main Menu
If you have an LCD printer, you can change the printer command
language from the Main Menu.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 From the Ready screen, press . The Main Menu appears.
3 In the Main Menu, select Settings > System Settings > General.
4 In the General settings list, press to scroll to Command
Language.
5 Press or to select a different command language.
6 Press or .
7 Press to save your changes.
If you are prompted to enter a password for ZSim, the password is
1138. To return to the Fingerprint menu system from ZSim, the
password is 8311.
Set the Command Language with the Print Button
If you have an icon printer, you can use the Print button to set the
printer command language.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 Turn off the printer.
3 Turn the printer back on. All the LEDs light up. As the printer
starts up, the LEDs turn off one by one, starting with the bottom
right LED.
4 When the last two LEDs (Maintenance and Bluetooth) are lit, press
and hold
. The printer feeds a few labels as it automatically
adjusts the media feed, and then the test labels start to print.
5 Continue to hold . The available printer command languages
start to print.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
