Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 37
About Tear-Off Printing
In tear-off printing, you manually tear printed labels, tickets,
wristbands, and other printed media from the front of the printer.
After you load media, you need to configure the feed adjust settings.
These settings allow for printing from the top edge of the label. You
may need to adjust the recommended values slightly depending on
your media type, supply method, and roll sizes, or because of
individual differences between printers.
Note: Feed adjust values for simulator command languages like ESim,
ZSim, and DSim are preset.
Recommended Feed Adjust Values for Tear-Off Printing
Printer Setting 203 dpi 300 dpi Distance
PC23d Start Adjust -113 -168 -14.24 mm (-0.56 in)
Stop Adjust 0 0 0 mm (0 in)
PC43d Start Adjust -124 -183 -15.50 mm (-0.61 in)
Stop Adjust 0 0 0 mm (0 in)
PC43t Start Adjust -108 -160 -13.60 mm (-0.54 in)
Stop Adjust 0 0 0 mm (0 in)

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
