Intermec PC43t User Manual

Appendix B — Default Settings
PC23 and PC43 Desktop Printer User Manual 147
Media Settings
This section describes media settings for the printer. To view these
settings:
• From the printer Main Menu, selectSettings > Printing > Media.
• From the printer web page, click the Configure tab, Printing >
Media.
Alert Notification
Method
Selects how you want the printer to
notify you of printer alerts.
SNMP Trap +
Email
Unit of Measure Selects the unit of measure that is
used to define several printing
parameters.
Dots
General System Settings (Continued)
Setting Description Default
Note: If you are using an icon printer that is not on a network, you
need to use PrintSet 5 through a USB connection to configure media
settings.
Media Settings
Setting Description Default
Media Type Selects the type of media that is loaded in
the printer.
Media With
Gaps
Print Method Selects the method of printing that the
printer is using.
Ribbon (TTR)
for thermal
transfer
printers, or No
Ribbon (DT)
for direct
thermal
printers

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
