Intermec PC43t User Manual

Chapter 1 — About the Printers
30 PC23 and PC43 Desktop Printer User Manual
Battery Precautions
Follow these precautions when using the printer with the Battery Base:
• Use only the battery supplied by Intermec. Risk of explosion if
battery is replaced by an incorrect type. Use of another battery may
present a risk of fire or explosion.
• The battery may present a fire or chemical burn hazard if
mistreated.
• Do not disassemble the battery, heat above 100 °C (212 °F), or
incinerate.
• Dispose of any used batteries according to the instructions that
came with the battery.
Charge the Battery
When the battery base is connected to AC power, the LEDs indicate the
charging status of the battery.
1 Make sure that the PC43d is properly installed on the base. For
help, see the
PC43d Battery Base Installation Instructions.
2 Connect the power cord from the battery base to the printer.
Battery is 0% to 10% charged.
Battery out of operating temperature
range.
Battery error.
LEDs: Battery Base Not Connected to AC Power (Continued)
LEDs Battery Charge Level

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
