Intermec PC43t User Manual

Chapter 1 — About the Printers
6 PC23 and PC43 Desktop Printer User Manual
About the Front Panel
There are two front panels available for the printers:
• LCD (liquid crystal display)
• Icon (no display)
Both versions of the front panel contain the Print button and the
Ready-to-Work™ indicator. Printers with the LCD also have a USB
host port on the front panel.
About the Ready-to-Work Indicator
The Ready-to-Work indicator on the front of the printer turns on
when the printer is ready to print.
Ready-to-Work Indicator Location
Ready-to-Work Indicator Status
Ready-to-Work Indicator Status Description
On Printer is ready for a print job.
Blinking Printer is not ready for a print job.
3FBEZUP8PSL
JOEJDBUPS

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
