Chapter 3 — Connect the Printer
PC23 and PC43 Desktop Printer User Manual 73
About Wi-Fi Communications
The printer supports Wi-Fi communications when the optional
Wi-Fi/Bluetooth module is installed.
You can configure Wi-Fi communications:
• from the printer web page. You need to know the printer IP
address.
• from the printer Main Menu if your printer has a graphical
interface.
By default, the printer supports DHCP networks. If you are not using
a DHCP network and you do not know the printer IP address, you need
to configure Wi-Fi settings by using Intermec PrintSet 5 through a
USB connection to the printer, or by sending commands through a
serial connection.
Connect the Printer to a Wireless Network
Before you begin, you should be familiar with the settings you need for
your network.
If you are using a DHCP network, turn the printer on. The printer
automatically connects to the wireless network.
For a printer with the LCD interface, the Wi-Fi Connection icon shows
the status of the connection.
Fingerprint
10.200.27.89
01/04/2012
12:00
®
$POOFDUJPOJDPO
Ready

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
