Intermec PC43t User Manual

Chapter 3 — Connect the Printer
74 PC23 and PC43 Desktop Printer User Manual
For a printer with the icon interface, the Wi-Fi icon turns on to show
that Wi-Fi is enabled.
If you are not using a DHCP network, follow the next procedure to
manually assign network settings (such as the printer IP address) to a
printer with the LCD interface.
1 From the printer Ready screen, press . The Main Menu appears.
2 Select Settings > Communications > Wireless 802.11.
8JSFMFTTJDPO
Note: If you are using an icon printer and you do not know the printer
IP address, you need to use Intermec PrintSet 5 with a USB connection
to a PC to configure wireless network settings for a non-DHCP
network.
Main Menu
Programs
Settings
Tools
Wizards
Wireless 802.11
General
Security
Network

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
