Appendix A — Specifications
126 PC23 and PC43 Desktop Printer User Manual
PC43t Physical Specifications
Dimensions: 18.2 cm x 21.1 cm x 28.1 cm (7.17 in x 8.31
in x 11.06 in)
Weight: 2.70 kg (5.95 lbs)
Power Supply Requirements: 100–240 VAC, 50–60 Hz, 60 W
Operating Temperature: 5 °C to 40 °C (41 °F to 104 °F)
Storage Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Relative Humidity: 20 to 80% non-condensing
PC43t Print Speed, Resolution, and General Media Specifications
Print Mode: Thermal transfer or direct thermal
Print Speed (variable): 203 dpi: 50 to 200 mm/sec (2 to 8 ips) 300
dpi: 50 to 150 mm/sec (2 to 6 ips)
Print Resolution: 203 dpi: 8 dots/mm300 dpi: 11.8
dots/mm
Print Width: 203 dpi: 104 mm (4.09 in) max 300 dpi:
106 mm (4.17 in) max
Media Width: 19.05 to 118 mm (0.75 to 4.65 in)
Label Roll Diameter (maximum): 127 mm (5 in)
Label Length (minimum): 6.35 mm (.25 in)
Gap Length Between Labels: 2 to 10 mm (0.08 to 0.39 in)
Black Mark Length 3 to 10 mm (0.12 to 0.39 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 76.2 to 203 μm (3 to 8 mil)
Media Density:
60 to 181 g/m
2
Liner Opacity (maximum): 76% (TAPPI T425)
Ribbon Width 25.4 to 110 mm (1 to 4.33 in)
Ribbon Roll Diameter
(maximum)
68 mm (2.68 in)
Ribbon Core (I.D.) 12.7 mm or 25.4 mm (0.5 or 1 in)
Ribbon Core Length 110 mm (4.33 in) notched
Ribbon Wound Ink Side Out, only
