Intermec PC43t User Manual

Appendix A — Specifications
PC23 and PC43 Desktop Printer User Manual 133
Printer Information Labels
Label Description
Installed Hardware List of hardware modules in the printer,
including:
• Main logic board configuration
number
• Wireless 802.11 MAC address
• Ethernet
• Serial Port
• USB Device
• USB Host
• Bluetooth
• Thermal Printhead
• Front Panel
• Ribbon
• Power Supply Unit
Print Statistics Number of labels printed, current
odometer value, and total distance
printed.
System Information General product information, including:
• Firmware version
• Product name, configuration number,
serial number, system name, and
command language
• Printhead resolution
• Mean printhead resistance
• Total flash memory and available flash
memory
• Total RAM and free RAM

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
