9.2.3 Installation on the seat frame profile (adjustable seat)
Requirements:
• 5 mm Allen key
• Loosen the screw (1) with a 5 mm Allen key.
• Remove the screw (1), the washer (2), the seat belt, the sliding bushing (3) and the sliding
block (4) from the seat frame profile (5).
• Replace the safety belt.
• Refit the parts in the reverse order.
