Uninstalling the lighting circuit board:
• Switch the electronics OFF on the remote.
• Remove the rear cover, as described in chapter 8.1.1.
• Take exact note of the positions of all cables and the sockets that they are connected to. Mark
the connectors and sockets or take a photograph with a digital camera.
• Disconnect the plug (2) from the lighting circuit board (1).
• Loosen and remove both screws on the lighting circuit board (3).
• Replace the lighting circuit board.
Installing the lighting circuit board:
• Assemble the parts in reverse order.
• Reconnect all cable connectors to their former positions.
• The last step is to test all functions of the vehicle.
