• Rear drillholes (1)
• Front drillholes (2)
Note
For adjusting the seat depth should be first the
seat frame secured in the median position on the
base frame.
To adjust the seat depth, proceed as follows:
• Loosen screws (3)
• Push the front seat section forwards or
backwards
• Retighten the screws (3)
Modulite seat
The seat depth is adjusted by shifting the position of the backrest.
See User Manual.
10.2 Adjusting the seat angle
The seat height is adjusted via the seat angle and the actuator holder.
There are two kinds of the seat angle adjustment:
A = 12°- Seat angle adjustment (Standard seat and Flex2 seat)
B = 20°- Seat angle adjustment (Flex2 seat and Modulite seat)
