Invacare Kite - Replacing Light Bulbs in the Front (Conventional Lighting System)

SERVICE MANUAL
Invacare
®
- Kite
56
8.7.4 Replacing light bulbs in the front (Conventional lighting system)
Requirements:
• Phillips screwdriver size 2
• Loosen the concealed Phillips head screw (1) on the back of the head lamp / turn indicator
combination.
• Remove the transparent plastic cover.
• Replace the defective light bulb.
• Reposition the cap and tighten the Phillips head screw hand-tight.
