Uninstalling the G-Trac sensor:
• Switch the electronics OFF on the remote.
• Remove the rear cover, as described in chapter 8.1.1.
• Take exact note of the positions of all cables and the sockets that they are connected to. Mark
the connectors and sockets or take a photograph with a digital camera.
• Disconnect the plug (3) of the G-Trac sensor (1) from the power module. (2).
• Loosen the M6 nut (4) and push the G-Trac sensor upwards.
• Pull the G-Trac sensor backward and out.
• Replace the G-Trac sensor.
Installing the G-Trac sensor:
• Insert the square-end piece into the slot provided for this purpose.
• When installing the G-Trac sensor, make sure it is positioned exactly vertical.
• Reconnect all cable connectors to their former positions.
• The last step is to test all functions of the vehicle.
