ATTENTION: Danger of crushing!
The seat/seat support is very heavy. Danger of injury to hands and feet!
• Use proper lifting techniques
Requirements:
• 10 mm Allen wrench
• 13 mm open-ended wrench
• 24 mm open-ended wrench
• 24 mm box wrench
• Side cutting pliers
• Cable ties
• Remove the legrests.
• If possible, tilt the seat back as far as it will go.
• Switch the electronics OFF on the remote.
• Remove the rear and the middle covers, as described in chapter 8.1.1 und 8.1.2.
• Take exact note of the positions of all cables and the sockets that they are connected to. Mark
the connectors and sockets or take a photograph with a digital camera.
• Disconnect the plug (1) of the actuator to be tested from the actuator module.
• Pull the actuator cable out of the wheelchair. If necessary, also remove the cable ties.
