Invacare Kite - 12° Adjusting the Seat Angle with Standard Seat or Flex2 Seat

Invacare
®
- Kite
SERVICE MANUAL
129
10.2.1 12° Adjusting the seat angle with Standard seat or Flex2 seat
Requirements:
• 4 mm Allen wrench
• 13 mm open-ended wrench
• Screwdriver, flat, width approx. 6 mm
• Small hammer
ATTENTION: Danger of crushing!
The seat is very heavy. Danger of injury to hands and feet!
• Use proper lifting techniques.
Overview of the fixations points, depending on the desired seat height and the seat which is
installed:
Seat
height
in cm
12° tilt with standard seat Actuator holder
A B C D a b c d
42 X X
44 X X
46 X X
48 X X
Seat
height
in cm
12° tilt with Flex2 seat Actuator holder
A B C D a b c d
46 X X
48 X X
50 X X
