Invacare Kite - Simple Seat

SERVICE MANUAL
Invacare
®
- Kite
144
10.3.3.2 Simple seat
Requirements:
• 6 mm Allen key
• Remove the seat plate (1) or the sling seat, see chapter 8.19.1.
• Loosen the socket head screws (2) in the front and rear, left and right – DO NOT remove.
• Shift the position of the seat frame.
• Re-tighten the screws.
• Install the seat plate again.
