ATTENTION: Danger of crushing to the hands and feet by the weight of the wheelchair!
• Pay attention to the hand and feet.
• Use proper lifting techniques.
Danger of injury due to uncontrolled movement of the wheelchair!
• Switch the vehicle's power system off (ON-/OFF key).
• Engage the drive motors.
• Secure the vehicle against rolling away by placing wedges under the wheels.
Requirements:
• 24 mm socket wrench
• 24 mm open-ended wrench
• Flat screwdriver
• Oblong wooden blocks, at least 14 x 14 x 30 cm
• Medium strength thread locking adhesive, for example Loctite 243
Removing the wheel:
• Prop up the wheelchair on multiple wooden blocks. Use proper lifting techniques.
• Use a Phillips screwdriver to remove the plastic cap (5).
• Heat up the nut (4) using the heat gun to soften up the thread locking adhesive.
Alternatively, you can counter the axle (2) using a 24 mm wrench to prevent it from rotating.
• Loosen and remove the nut with a 24 mm socket spanner.
