Invacare Kite - Adjustable Seats

Invacare
®
- Kite
SERVICE MANUAL
143
10.3.3.1 Adjustable seats
Requirements:
• 6 mm Allen key
• Remove the seat plate or sling seat (1), see chapter 8.19.1.
• Loosen the socket head screws (2) in the front and rear, left and right – DO NOT remove.
• Shift the position of the seat.
• Re-tighten the screws.
• Install the seat plate or the sling seat again.
