the fixation screws can be inserted into the
corresponding variation holes:
1 – Hinten
2 – Mitte
3 – Vorne
With the three holes on the seat frame five
variants are possible.
• Replace the fixation screws and tighten.
• Re-install all seat components.
CAUTION!
Danger of injury and damage to property!
If the castor wheels collide with parts of the wheelchair, the castor wheels can become
jammed, causing the wheelchair to tip.
• After adjusting the seat depth, always check that the castor wheels can move freely during
forward and backward driving and do not touch static parts of the wheelchair.
