Before you connect mobility aid components such as actuators or motors, please begin by
ascertaining which module is installed. Please refer to the following table for an overview of ACS 2
modules.
Electronicmodule Name Description
ACS 2 70
ACS 2 70L
ACS 2 90L
ACS 2 90L G
ACS 2 wiith ACT actuator module
See chapter 4.2.1
See chapter 4.2.1
See chapter 4.2.1
See chapter 4.2.2
See chapter 4.2.3
The actuator module is
optional.
Actuator module
ACT 2
ACT 4
See chapter 4.2.3.1
See chapter 4.2.3.2
The actuator module is
optional.
Lighting PCB See chapter 4.2.4
The lighting PCB is optional.
G-Trac sensor The G-Trac sensor is
optional.
Operation hour counter The operation hour counter
is optional.
