Invacare Kite - Page 46

SERVICE MANUAL
Invacare
®
- Kite
46
• Disconnect the battery cable from the electronic module.
• Loosen and remove both of the knurled head screws (4).
• Loosen and remove the knurled head screws (2).
• Turn the rear cover (1) down along with the electronic modules.
• Pull foam rubber block (3) backwards out of the battery box.
