iPECS-MG
Hardware Description and Installation Manual Issue 1.1
7
2.4 General Specifications
2.4.1 Dimension and Weight
ITEM HEIGHT (mm) WIDTH (mm) DEPTH (mm) WEIGHT (kg)
BKSU 170.2 440 325.4 6.2
EKSU 170.2 440 325.4 6.25
Digital Keyset* 268 203 124 0.9
Digital DSS/DLS Console 154 175 111 0.4
Digital ICM/Door Box 32 132 99 0.5
Digital Data Module 37 175 148 1.5
Base Station (600B/ 600BE) 170 220 57 0.46
Wireless
Terminal
GDC–33xH 145 50 35 0.15
GDC–34xH 131 49 32 0.102
GDC–4xxH 133 44 20 0.92
* Digital Keyset: LDP-7024D, Digital DSS: LDP–7048DSS, Digital Door Box: LDP-DPB
2.4.2 Environment
ITEM DEGREES (°C) DEGREES (
°F
)
Operation Temperature 0–40 32–104
Optimum Operation Temperature 20–26 68–78
Storage Temperature 10–70 32–158
Relative Humidity 0–80% non–condensing
2.4.3 System Electrical
ITEM SPECIFICATION (PSU)
1. Power Supply
– AC Voltage Input 100–240 Volt AC @47–63Hz
– AC Power 350W
– AC Input Fuse 6.3A @ 250Volt AC
– DC Output Voltage + 5, + 30Volt DC
2. Battery Backup
–PSU Input Voltage 24Volt DC
–PSU Battery Fuse 15.0A @250Volt AC
–Charging Current Max. 1A
