iPECS-MG
Hardware Description and Installation Manual Issue 1.1
8
2.4.4 PSU Fan
ITEM SPECIFICATION
Maker / part number POWERLOGIC / PLA07015B05H
Dimensions 70 X 70 X 15 (mm)
Rated voltage +5V
2.4.5 DECT Base Station (GDC-400B/GDC-600B/GDC-600BE)
ITEM SPECIFICATION
Power feeding +30V DC
Transmission Max. Power 250mW
Access Method/Duplex TDMA/TDD
Frequency Band 1, 880–1, 900MHz
Channel Spacing 1.728MHz
Modulation GFSK
Data rate 1.152Mbps
Max. Base Station distance from the WTIB 600m (twisted 2–pair cable)
2.4.6 Station Distance from the System
ITEM 22 AWG Wire (m/kft) 24 AWG Wire (m/kft)
Digital Keyset 500 / 1.6 330 / 1
Single Line Telephone 7, 500 / 24.6 5, 000 / 16.5
