 4 Status Indication LEDs
 1 RS-232C serial port
 1 Reset Button
 1 Switch for Admin Database back up
 1 External MOH port
 1 External Paging port
 1 Alarm Detection port
 1 Relay Contact for general purpose
 1 USB port for DB upload and download, SW upgrade with Memory stick
 1 Ethernet port – System maintenance, SW upgrade, and basic 4 channel VoIP
Table 5.2-1 MPB 100 and MPB 300
ITEM MPB100 MPB300 REMARK
SRAM 2ea (4MB) 4ea (8MB) User Data back up
ACT2 32 DSP channels 64 DSP channels
DTMF, CPT, CID Detection
channels
MAX Ports 200 414
Available MAX (Trunk +
Extension) Ports
NOTE
Except MAX Ports, RAM, and DSP channels, all functions of both MPB100 and
MPB300 are the same.
5.2.1 Switch and LED Functions
The MPB has various switches and LEDs (refer to the following table).
Table 5.2.1-1 Connector Jack and Switch Functions
SWITCH & CONNECTOR FUNCTIONS DESIGNATION
SW1-1 Database Protect MODE
SW1-2 Memory Battery BAT
SW2 System Reset
PJ1 (Red) External MOH Connection MOH
PJ2 (Blue) External PAGE Connection PAGE
MJ3 (RJ45)
Alarm Sensor and External Relay
Contact
ALM/RLY
MJ2 (RJ45) USB port USB
MJ1 (RJ45) LAN Port LAN
