5.5.1.1 Switch, and LED Functions
Table 5.5.1.1-1 Switch Functions
SWITCH FUNCTION REMARK
SW1 4-POLE Dip Switch (Function : not defined) Default: Off
SW2
SW3 Reset switch
SW4
Table 5.5.1.1-2 LED Indication
LED FUNCTION REMARK
LD1 Normal operation indication (Activity Indication) Blink (blue Color)
LD2 Memory Full (ON – Full, OFF – Usable) AAIB – Not used
LD3 Record (ON – Active, OFF – Idle)
LD4 Play (ON – Active, OFF – Idle)
RJ45-LD1
(Green/Orange)
ON – Link, Blink – Data Transfer
RJ45-LD2 (Yellow) ON - 100Mbps, OFF – 10Mbps
5.5.1.2 VMIB and AAIB Installation
The VMIB and AAIB have no switches or connectors that are field useable. The VMIB and
AAIB can be installed in any universal slot of any KSU; the 1st slot of the BKSU is for the MPB
only. A maximum of two boards may be installed in the iPECS-MG100 and three (3) in the
iPECS-MG300.
 Assure Power is OFF
 Slide the VMIB/AAIB in the guide rails of the desired slot.
 Tighten thumbscrews to hold the board firmly in place.
5.5.1.3 VMIB and AAIB Wiring
There is no wiring required for proper operation of the VMIB or AAIB.
