iPECS iPECS-MG - SLIBC Installation; SLIBC Wiring

iPECS-MG
Hardware Description and Installation Manual Issue 1.1
60
Table 5.4.2.1-1 LED Indications
LED FUNCTION REMARK
LD11
The status of 11
th
port or 23
rd
port
ON (Blue) : 11
th
port Use
ON (Yellow Green) : 23
rd
port in use
ON (Blush white) : 11
th
and 23
rd
port in use
OFF: Idle
LD12
The status of 12
th
port or 24
th
port
ON (Blue) : 12
th
port in use
ON (Yellow Green) : 24
th
port in use
ON (Blush white) : 12
th
and 24
th
port in use
OFF: Idle
LD13
ACT, Activation or Normal Operating Blink (Blue Color)
LD14
In use
ON: Ch. Use,
OFF: All channels Idle
5.4.2.2 SLIBC Installation
The SLIB has no switches or connectors that are field useable. The SLIB can be installed in
any universal slot of any KSU; the 1st slot of the BKSU is for the MPB only. Note a maximum of
four (4) DTIB24/SLIB24Cs can be installed in a KSU.
 Assure Power is OFF
 Slide the SLIBC in the guide rails of the desired slot.
 Tighten thumbscrews to hold the board firmly in place.
5.4.2.3 SLIBC Wiring
Each SLT port is terminated to a pair in the RJ21 connector. SLT 1 is terminated at pair 1, SLT
2 is terminated on pair 2, etc. to the number of ports (12 or 24) on the SLIBC.
Referring to the pin-out chart below,
 Wire each SLT pair on the RJ21 connector to the SLT termination point using UTP
cable. The maximum total wire length is 7500M/24Kft of 22 AWG wire or
5000M/16Kft of 24 AWG wire. For information on wiring the SLT, refer to section
6.1.2.2
 Tag or number wiring for maintenance.
