6. TERMINAL CONNECTION AND
WIRING
6.1 Terminal and Door Phone Models
Various types of digital terminals and IP Terminals can be used with the iPECS-MG as listed in
the table and shown below. Other older model digital phones may also be compatible with the
iPECS-MG, check with your local Ericsson-LG representative for details.
Digital Key Telephones connect to the DSIU or a DTIB. IP Key Telephones connect to the LAN
where they have access to a VOIB channel.
MODEL DESCRIPTION
LDP-7004N 4 Flexible Button No display
LDP-7004D 4 Flexible Button w/Display
LDP-7008D 8 Flexible Button w/Display
LDP-7016D 16 Flexible Button w/Display
LDP-7024D 24 Flexible Button w/Display
LDP-7024LD 24 Flexible Button w/Large Display
LDP-7048DSS 48 Button DSS/DLS Console
LDP-DPB Door Phone Box
LIP-7008D 8 Flexible Button w/Display
LIP-7016D 16 Flexible Button w/Display
LIP-7024D 24 Flexible Button w/Display
LIP-7024LD 24 Flexible Button w/Large Display
LIP-8002 4 Feature Button w/Display
LIP-8004D 4 Flexible Button w/Display
LIP-8008D 8Flexible Button w/Display
LIP-8012D 12 Flexible Button w/Display
LIP-8024D 24 Flexible Button w/Display
LIP-8040L 10 Flexible Button w/Large Display
LIP-8012DSS 12 Button DSS Console / Power supply
LIP-8012LSS 12 Button LSS Console / via keyset up to 2
LIP-8048DSS 48 Button DSS Console / via external up to 4
LIP-8040LSS 48 Button DSS Console w/Display via external or PoE up to 9
LIP-8002E/2AE 4 Feature Button w/Display
LIP-8008E 8 Flexible Button w/Display
LIP-8012E 12 Flexible Button w/Display
LIP-8024E 24 Flexible Button w/Display
LIP-8040E 10 Flexible Button w/Large Display
LIP-8050V 5 Flexible Button, w/Color Display & Video Camera
