5.4.4.1 LED Functions
Table 5.4.6.1-1 LED Indication
LED FUNCTION REMARK
LD1 The status of 1
st
port or 13
th
port
ON (Blue) : 1
st
port Use
ON (Yellow Green) : 13
th
port Use
ON (Blush white) : 1
st
and 13
th
port Use
OFF: Idle
LD2 The status of 2
nd
port or 14
th
port
ON (Blue) : 2
nd
port Use
ON (Yellow Green) : 14
th
port Use
ON (Blush white) : 2
nd
and 14
th
port Use
OFF: Idle
LD3 The status of 3
rd
port or 15
th
port
ON (Blue) : 3
rd
port Use
ON (Yellow Green) : 15
th
port Use
ON (Blush white) : 3
rd
and 15
th
port Use
OFF: Idle
LD4 The status of 4
th
port or 16
th
port
ON (Blue) : 4
th
port Use
ON (Yellow Green) : 16
th
port Use
ON (Blush white) : 4
th
and 16
th
port Use
OFF: Idle
LD5 The status of 5
th
port or 17
th
port
ON (Blue) : 5
th
port Use
ON (Yellow Green) : 17
th
port Use
ON (Blush white) : 5
th
and 17
th
port Use
OFF: Idle
LD6 The status of 6
th
port or 18
th
port
ON (Blue) : 6
th
port Use
ON (Yellow Green) : 18
th
port Use
ON (Blush white) : 6
th
and 18
th
port Use
OFF: Idle
LD7 The status of 7
th
port or 19
th
port
ON (Blue) : 7
th
port Use
ON (Yellow Green) : 19
th
port Use
ON (Blush white) : 7
th
and 19
th
port Use
OFF: Idle
LD8 The status of 8
th
port or 20
th
port
ON (Blue) : 8
th
port Use
ON (Yellow Green) : 20
th
port Use
ON (Blush white) : 8
th
and 20
th
port Use
OFF: Idle
LD9 The status of 9
th
port or 21
st
port
ON (Blue) : 9
th
port Use
ON (Yellow Green) : 21
st
port Use
ON (Blush white) : 9
th
and 21
st
port Use
OFF: Idle
LD10 The status of 10
th
port or 22
nd
port
ON (Blue) : 10
th
port Use
ON (Yellow Green) : 22
nd
port Use
ON (Blush white) : 10
th
and 22
nd
port Use
OFF: Idle
