5.5 Function Boards
5.5.1 VMIB (Voice Mail Interface Board) and AAIB (Auto-Attendant
Interface Board)
The VMIB and AAIB provide memory for System Greetings including CCR and ACD/UCD
announcements. In addition, the VMIB provides memory for User Greetings and Voice
Message storage, 100 hours. The VMIB and AAIB include a processor and DSP circuitry to
support eight (8) simultaneous channels. For additional channels and/or storage capacity, two
(2) VMIBs or AAIBs may be installed in the iPECS-MG100 (16 total channels) and up to three
(3) VMIBs or AAIBs may be installed in the iPECS-MG 300 (24 total channels).
BOARD CHANNEL
SYSTEM GREETING
USER GREETING
VMIB 8 System Greeting (0.5hrs.), User Message (100 Hours)
AAIB 8 System Greeting (0.5hrs.), User Message (None)
The VMIB and AAIB have a standard USB connector that is used to back-up System and User
greetings, and Voice Messages (VMIB only). In addition, the VMIB and AAIB have a LAN and
Audio Serial port jack used for advanced diagnostic purposes and board upgrades only.
Figure 5.5.1-1 AAIB and VMIB
NOTE
 If VMIB or AAIB is installed in a System, VMIB/AAIB prompts (Default=1-English, 2-
3-Blank) should be uploaded for each country.
 System Voice prompts are stored on the MPB and not the VMIB or AAIB.
 Voice prompt Language can be changed using the Web Admin, VMIB upgrade
function.
