5.2.5.2 Page Audio Connector Wiring
The Page connector allows paging audio to be sent to External Paging equipment. The system
will deliver audio as a 0-dBm signal into a 600-ohm load.
Referring to Figure 5.2.5-1,
Wire the Page Audio connector to the termination point of the audio input of the
External Page equipment.
Tag or number wiring for maintenance.
5.2.5.3 MOH Connector Wiring
When a call is placed on hold, MOH (Music on Hold) is presented to the caller. MOH can be
provided from an internal source or from an external audio source connected to the MOH
connector.
Referring to Figure 5.2.5-1,
Wire the MOH connector to the termination point of the audio output of the external
MOH source.
Tag or number wiring for maintenance.
5.2.6 USB Connector
The USB connector is provided to allow a USB memory stick to connect to the system for
upload and download of the System database. No wiring of the USB connector is required. For
further information on operation of the USB port, refer to the iPECS-MG Admin Manual.
Table 5.2.6-1 USB Connector
CONNECTOR PIN SIGNAL NAME
USB Type A
1 GND
2 D+
3 D-
4 VBUS (+5V)
