5.4.5.1 Connectors, Switch and LED Functions
The following Table shows the relation between the front panel RJ45 connectors and
associated Base Station (cell) numbers.
Table 5.4.5.1-1 WTIB RJ45 Connector Functions
CONNECTOR CELL NUMBER
BS1 Cell 1
BS2 Cell 2
BS3 Cell 3
BS4 Cell 4
BS5, WTIB8 only Cell 5
BS6, WTIB8 only Cell 6
BS7, WTIB8 only Cell 7
BS8, WTIB8 only Cell 8
Table 5.4.5.1-2 Switch Functions
SWITCH ON OFF DESCRIPTION DEFAULT
SW3-1 Test mode Normal TRB6 Test Mode OFF
SW3-2 Enable Echo-can. Disable Echo-can. Echo-canceller control ON
SW3-3 Not used ON
SW3-4 All base reset Only new base reset On: All base reset
Off: One base reset
OFF
The nine (9) LEDs mounted on the WTIB indicate the status of the board as explained in the
chart below.
Table 5.4.5.1-3 WTIB LED Indications
LED NORMAL LABEL
1 ON: Master WTIB, Toggle: Slave 1 WTIB, OFF: Slave 2 WTIB M/S
2 When Nios CPU is normal, TMR LED toggles every 100msec. TMR
3 ON: DSP Echo cancellation enabled, OFF: DSP Echo cancellation disabled DSP
4 When more than one DECT channel is used, LED8 is ON. IN USE
5 When WTIB is connected with MPB, CON LED is ON. CON
6 When WTIB sends or receives data from MPB, IP LED toggles. IP
7 When WTIB sends or receives data from Base Station, E1 LED toggles. E1
8 When WTIB sends or receives data from other WTIB, WBUS LED toggles. WBUS
