iPECS iPECS-MG - KSU Diagram, Exterior and Dimension

iPECS-MG
Hardware Description and Installation Manual Issue 1.1
19
4.3 KSU Diagram, Exterior and Dimension
For reference purposes, Figure 4.3-1 shows the exterior and dimensions of the KSU.
Figure 4.3-1 KSU Exterior and Dimension
