CONNECTOR TYPE
MATING-CONNECTOR BOARD PURPOSE
RS–232C
MPB Serial Port
Serial to Audio Jack
VOIB8, VOIB24, VMIB,
AAIB PRIB, BRIB2,
BRIB4, WTIB4, WTIB8
Serial Port
Audio Jack
MPB EXT MOH Port
EXT PAGE Port
