iPECS-MG
Hardware Description and Installation Manual Issue 1.1
45
Table 5.3.2.1-3 BRIB Power Feed
SWITCH FUNCTION ON OFF
SW7-1 Line 1 Power Feed (-40V) Feed Open
SW7-2
Line 1 Power Feed
(Ground)
Feed Open
SW9-1 Line 2 Power Feed (-40V) Feed Open
SW9-2
Line 2 Power Feed
(Ground)
Feed Open
SW11-1 Line 3 Power Feed (-40V) Feed Open
SW11- 2
Line 3 Power Feed
(Ground)
Feed Open
SW13-1 Line 4 Power Feed (-40V) Feed Open
SW13-2
Line 4 Power Feed
(Ground)
Feed Open
Table 5.3.2.1-4 LED Indication, BRIB2
NO FUNCTION STATUS
LD1
LD3
Line 1 status Red: ON = Error
Blue: ON = In-use, OFF = Idle
LD2
LD4
Line 2 status Red: ON = Error
Blue: ON = In-use, OFF: = Idle
Table 5.3.2.1-5 LED Indication, BRIB4
NO FUNCTION STATUS
LD1
LD5
Line 1 status Red: ON = Error
Blue: ON = In-use, OFF = Idle
LD2
LD6
Line 2 status Red: ON = Error
Blue: ON = In-use, OFF = Idle
LD3
LD7
Line 3 status Red: ON = Error
Blue: ON = In-use, OFF = Idle
LD4
LD8
Line 4 status Red: Error
Blue: ON = In-use, OFF = Idle
