iPECS-MG
Hardware Description and Installation Manual Issue 1.1
69
Table 5.4.5-1 System DECT Base Station Specifications
ITEM SPECIFICATION
Power Feed required +30 VDC
Transmission Max Power 250 mW
Access Method/Duplex TDMA/TDD
Frequency Band 1,880 ~ 1,900MHz
Channel Spacing 1.728MHz
Modulation GFSK
Data Rate 1.152Mbps
Max. Base Station distance from the WTIB4/8 600m (twisted 2-pair cable)
Max. Transmission Power 250 mW
Modulation Method GFSK
Frequency Band 1,880MHz ~ 1,900MHz
The WTIB provides power to the System DECT Base Stations and is the interface between
Base Stations and other resources and features of the iPECS-MG. The iPECS-MG100
supports two (2) WTIBs and the iPECS-MG300 will support three (3) WTIBs. Each port on the
WTIB terminates to an RJ45 connector on the front panel of the board.
