ISHIDA UNI-7 Service Manual

Chapter 9 ERROR SCREENS
ERROR ID NOS. 312 – 396
ID NO. TITLE TEXT
312-
000
LABEL IS REMAINING
* LABEL IS REMAINING.
REMOVE LABEL
312-
001
LABEL IS REMAINING REMOVE LABEL ON APPLICATOR.
313 PRINTER THERAML HEAD IS UP
* THERMAL HEAD IS UP.
SET THERMAL HEAD
316
MARK DOWN PRICE IS MORE THAN
ORIGINAL PRICE
CHECK PRICE.
NORMAL PRICE[* $] MARK DOWN PRICE[* $]
317
VARIOUS PRICE IS LOWER THAN
ORIGINAL PRICE
CHECK PRICE.
NORMAL PRICE[* $] VARIOUS PRICE[* $]
318
MARK DOWN UNIT PRICE IS LESS
THAN ORIGINAL PRICE.
CHECK UNIT PRICE.
NORMAL UNIT/PRICE[* $] MARK DOWN UNIT
PRICE[* $]
319
PRODUCTION FOR TARGET IS
COMPLETED
CHECK TARGET No.
CLEARS TARGET No.
321 PRICE IS NOT PROGRAMMED ENTER PRICE
339
LOWER VALUE IS LESS THAN FIXED
WEIGHT
IF YOU CHANGE FIXED WEIGHT [* g] TO [* g]
342 POS CODE IS NOT PROGRAMMED
POS CODE IS NOT PROGRAMMED
AFTER PROGRAMMING IT
343 POS CODE IS NOT PROGRAMMED
POS CODE IS NOT PROGRAMMED.
BARCODE CAN NOT BE PRINTED.
347-
000
THERMAL HEAD IS WORN OUT
IT WORNS OUT WHERE IT DOES NOT EFFECT
ON PRINTING.
NO PROBLEM ON PRICING LABEL.
DO YOU WANT TO CHECK?
PRESS (EXEC) TO CHECK.
DOES NOT CHECK (STOP).
347-
001
THERMAL HEAD IS WORN OUT
IT IS WORN OUT SIDE OF FORMAT
YOU NEED TO CHANGE THERAMAL HEAD.
DO YOU WANT TO CHECK?
START CHECKING WITH (EXEC).
(STOP) DO NOT CHECK
347-
002
THERMAL HEAD IS WORN OUT
IT IS NOT PRITNING BARCODE CORRECTLY.
CHANGE THERMAL HEAD.
YOU CAN NOT DO THE WORK.
351 LABEL IS REMAINING REMOVE LABEL
356 THERE IS NO CF CARD CHECK CF CARD.
357 THERE IS NO DICTIONARY FILE CHECK CF CARD.
361 POWER IS ON CHECK SCALE FOR STARTING PRODUCTION.
396 NO USB MOMORY CHECK USB MEMORY
9-4 UNI-7 Service Manual

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
