Chapter 4 ELECTRICAL SIGNALS
4.4 WIRELESS LAN BOARD (PK-265)
XJ1
No. Signal Name Direction Opposite Side
1
DC+5V -
2 GND -
PK-260 XJ12
XJ2
No. Signal Name Direction Opposite Side
1 TX+ →
2 TX- →
3 RX+ ←
6 RX- ←
10 LEDR -
11 LEDL -
4,7,13,14 GND -
9,12 DC+3.3V -
PK-260 XJ3
4-10 UNI-7 Service Manual
