ISHIDA UNI-7 - Motor Unit

Chapter 5 MACHINE DISASSEMBLY
5.6.7 MOTOR UNIT
1.
Make sure that the rear stainless-steel case is removed. (Refer to section 5.6.4)
3.
Remove the power supply unit. (Refer to
section 5.6.5)
4.
Remove the four fixing screws to detach the
motor unit.
UNI-7 Service Manual 5-37
